Penguin Diamond 企鵝


Specification 規格

DESIGN: 3 – way bass-reflex floor standing loudspeaker

FREQUENCY RESPONSE: 28-40K Hz ±2dB

SENSITIVITY (2.83V/1M): 86 dB

IMPEDANCE: 4 ohms

POWER REQUIREMENT: 100-150W recommended

TWEETER: Jantzen 1” diamond

REAR FIRING TWEETER: Accuton 1” ceramic

MIDWOOFER: Accuton 5” cell ceramic

WOOFER 1&2 Accuton 9” cell ceramic

CROSSOVER: 4th order design

CROSSOVER FREQUENCY: 2500Hz/300 Hz

CROSSOVER’S ATTENUATION SLOPE: Woofer -24dB, midrange -24db, Tweeter -24dB

CROSSOVER COMPONENTS:

High quality MKP capacitors. Also, high purified OFC, inductors and the metal oxide film resistors with military industrial standard.

CONNECTIVE CABLE: Teflon insulated OCC cable

TERMINALS: WBT Bi-wiring

CABINET MATERIAL: High quality 30mm MDF

CONNECTIVE CABLE: Teflon insulated OCC cable

FINISH: Rosewood

SPEAKER (HWD): 124cm×28cm×45cm

NET WEIGHT: 60kgs/pc

WOODEN CASE (HWD): 133x74x69cm, 55 kgs /pc

GROSS WEIGHT: 115kgs/pair
