Dove Diamond 鴿子


Specification 規格

DESIGN: 2-way vented-box

FREQUENCY RESPONSE: 35Hz-40kHz

SENSITIVITY (2.83V/1M): 91dB

IMPEDANCE: 4 ohms

POWER REQUIREMENT: 50-150W recommended

TWEETER: Jantzen 1” diamond

BASS-MIDRANGE: 2 x Accuton 7” ceramic

CROSSOVER: 4th order, 2800Hz

CROSSOVER FREQUENCY: 2500Hz/250 Hz

CROSSOVER’S ATTENUATION SLOPE: Woofer -24dB, Tweeter -24dB

CROSSOVER COMPONENTS:

High quality MKP capacitors. Also, high purified OFC, inductors and the metal oxide film resistors with military industrial standard.

CONNECTIVE CABLE: Teflon insulated OCC cable

TERMINALS: WBT single wiring

CABINET MATERIAL: High quality 25mm MDF

SPEAKER (HWD): 106cm×22cm×35cm, 27kgs/pc

WOODEN CASE (HWD): 60cm x 116cm x 74cm, 100kg/pair
